2022 Supreme ZS232

IN STOCK!

Stock #QSB5258
Check Availability Hi, my name is and I'm interested in this 2022 Supreme ZS . I'm in the area and you can reach me at or by phone at .



One look at the 23-foot 2-inch ZS232 from Supreme Boats, and you will know you are looking at a high-performance wakesurf boat. The 2022 ZS models are named for their Z-shaped sheer line, but internally they are known as the Zeus boats because riding one is like surfing a lightning bolt — embodying the mythical trinity of surf, wake, and ride. With as much as 4900 pounds of ballast at your fingertips and the tapered-v hull for bigger waves, you can launch to new heights from the powerful surf wave or cruise like you rule the water.



Ballast

As much as 4900 pounds of ballast available in the 2022 Supreme ZS232 in as many as six different individually pumped locations distributed evenly throughout the wakesurf boat.



Tapered-V Hull

The surfability of a Supreme begins at the water level with the modified deep-v hull design. The deep-v creates a smooth rough water ride with double the degree of V (20 degrees of deadrise) as competitors. The ‘modified’ piece of this design adds balance to the hull to guard against side-to-side weight shift negatively impacting the water behind the boat. Supreme ZS models expand the surfability of our modified deep-v hull with a tapered-v hull design that sits lower in the water towards the rear of the wakeboard boat when weighted, displacing more water with less weight to intensify the waves and wakes. Staggered Chine Stabilization (SCS) creates symmetrical waves and wakes. SCS is custom lifting rails on the starboard and port sides, staggered in their size and placement to balance the asymmetrical pitch of the boat due to the righthand drive configuration and natural prop rotation.



Surf

These water sports boats are designed and built to help you rule your surf wave like a titan! It starts at the water level with a modified deep-v created to displace more water with less ballast weight. Yet, the ZS232 is available with as much as 4900 pounds of ballast from the factory distributed evenly throughout the boat for a low bow rise smooth ride and to displace the entire running surface. This creates an extremely long wave with consistent push from face to curl. Whether you like to surf 20 feet behind the boat or right off the swim platform, the Supreme ZS232 wave has a sweet spot just for you. The available QuickSurf System creates lift opposite the surf side, displacing the surf corner to form the wave. Thanks to the evenly distributed 6-position ballast and the high speed Lenco rams that power QuickSurf, that wave can be transferred or mirrored on the opposite side in 1.8 seconds. Also with Supreme, you are not locked in to one wave style. With the combination of the Stinger Wake Plate or the new Silent Stinger option, QuickSurf, 6-location ballast settings, and ZerOff Speed Control, you have unbelievable control over the height, length, and shape of the surf wave. Out of the box, the ZS232 wave is incredible and easy to create, but through the amazing adjustability, the boat’s wakesurf performance can grow with your surfing skill.





*Price plus dest, tax, lic, dlr*

  • Status:
    New
  • Vehicle:
    2022 Supreme ZS232
  • VIN:
    FINZ5258C222
  • Model Number:
    ZS232
  • Color:
    SILVER METAL FLAKE/ CHARCOAL
  • Stock Number:
    QSB5258
  • Title:
    Clear
  • Location:
    Lynnwood Motoplex, Lynnwood, WA 98037
  • Warranty:
    Manufacturer's w/ Extended Available

AUDIO & COMMUNICATION

  • Bluetooth® Audio:
    Yes
  • Mobile App Instrumentation:
    Yes

CONVENIENCE

  • Bilge Pump Alarm:
    Yes
  • Bilge System Type:
    Automatic Siphon / Electric Pump

DRIVE LINE

  • Propulsion Type:
    Propeller

ENGINE

  • Bore (in):
    4
  • Bore (mm):
    101.6
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    9.67
  • Cooling:
    Water (Open Loop)
  • Cylinders:
    8
  • Displacement (cc):
    5964.9
  • Displacement (ci):
    364
  • Displacement (l):
    6
  • Emergency RPM Reduction:
    Yes
  • Engine Alert System Type:
    Visual / Audible
  • Engine Configuration:
    Inboard
  • Engine Manufacturer:
    PCM
  • Engine Model Code:
    ZR4 (409)
  • Engine Stroke:
    4-Stroke
  • Engine Trim:
    PCM ZR4 409
  • Engine Type:
    V8
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Full Throttle RPM Range High:
    5600
  • Full Throttle RPM Range Low:
    5400
  • Horsepower (bhp):
    409
  • Horsepower (kW):
    305.2
  • Horsepower RPM:
    5600
  • Number Of Engines:
    1
  • Salt Water Capable:
    Yes
  • Starter:
    Electric
  • Stroke (in):
    3.62
  • Stroke (mm):
    92
  • Torque (Ft Lbs):
    400
  • Torque (Nm):
    542.3
  • Valve Configuration:
    OHV
  • Valves Per Cylinder:
    2
  • Valves:
    16

EXTERIOR

  • Hull Material:
    Fiberglass

GLASS

  • Walk-Through Windshield:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge

STEERING

  • Outboard Steering Control:
    Remote
  • Steering Assist System:
    Yes

TECHNICAL SPECIFICATIONS

  • Beam (in):
    102
  • Beam (m):
    2.6
  • Draft (Drive Down) (in):
    36
  • Draft (Drive Down) (mm):
    914.4
  • Draft (Drive Up) (in):
    36
  • Draft (Drive Up) (mm):
    914.4
  • Dry Weight (kg):
    2472.1
  • Dry Weight (lbs):
    5450
  • Fuel Capacity (gal):
    70
  • Fuel Capacity (l):
    265
  • Length (ft):
    23.17
  • Length (ft/ft):
    23
  • Length (ft/in):
    2
  • Length (in):
    278
  • Length (m):
    7.1
  • Length (mm):
    7100
  • Max Recommended Horsepower (bhp):
    465
  • Max Recommended Horsepower (kW):
    347
  • Min Recommended Horsepower (bhp):
    409
  • Min Recommended Horsepower (kW):
    305.2
  • Number of Passengers:
    14
  • Number Of Water Ballast Tanks:
    1
  • Total Water Ballast Tank Capacity (gal):
    587.1
  • Total Water Ballast Tank Capacity (l):
    2219.2

TOPSIDE / CABIN

  • Cockpit Flooring Type:
    Marine Foam
  • Galley Table Configuration:
    No Galley Table
  • Helm Roof Type:
    Open Top
  • Helm Seating Configuration:
    Chair
  • Number Of Cockpit Sofas:
    1
  • Number Of Helm Seats:
    1
  • Number Of Open Bow Seats:
    3
